Ideal for noisy environments where traditional acoustic ceilings are not possible.
Class Above are engineered acoustical products giving exceptional levels of acoustic performance.
The baffles and rafts are installed using our unique suspension cable system enabling easy installation and removal. The fins are installed via circular hooped bolts which can be attached either to a suspended frame system or to hooks directly on the ceiling. For wall applications, the panels have an internal system to create a perfect floating finish.
BENEFITS
Hang from ceilings
Arrange and combine in various formation
Suspend from ceilngs
Layer in varying depths to create dramatic spaces
Using the same tried and tested recycled PET bottles as our exisiting range.
Cost effective solution for large installations
Sustainable design for envirnmentally concious projects
SPECIFICATIONS
TYPICAL APPLICATIONS
Wall coverings
- Composition: 100% Polyester
- Low VOC
- Colourfastness Properties
- Colourfastness to Light, AATCC16(3), Class 4.5
- BS EN ISO 354:L2003.
- Certified 100% Recyclable
- PET with over 50% Recycled content
FIRE RATING
- BS1 DO
- Suitable for use in Class1 and Class 0
SIZE
- 300 x 1200 x 50mm
- 600 x 600 x 50mm
- 600 x 1200 x 50mm
ACOUSTIC PROPERTIES
- NRC: 0.95
- EN ISO 11654:1997
INSTALLATION
Easy installation for ceilings
- Install the ceiling anchor.
- Insert CLASS ring into pre-formed hole on the rear of the panel.
- Attached suspension cable and adjust depth.
- Hang panel.
MOISTURE ABSORPTION
Polyester fibre when exposed to an atmosphere of 50°C at 90% relative humidity for four days showed moisture absorption of less than 0.03% by weight. Polyester is not affected by moisture.
Does not contain any Red List chemicals*.
COLOUR RANGE
White
Ash
Charcoal
Resources
